GENERAL
Specification
Value
Frequency Range(MHz)
VHF:144~148MHzUHF:430-440MHZ
Memory channels
200
Frequency stability
±2.5ppm
Frequency step(KHz)
2.5K/5.0K/6.25K/10.0K/12.5K/25.0K
Squelch Setup
CARRIER/CTCSS/DCS/5Tone/2TONE/DTMF
Antenna impedance
50 Ohm
Operating temperature
-20℃ to +60℃
Supply voltage
13.8V DC±15%
Dimension
95(W)×43(H)×155(D) mm
Weight
500g
Operating Temperature
-5°F-+140°F
RECEIVER
Broadband
Narrowband
Sensitivity
≤0.25μV
≤0.35μV
Channel choice
≥70dB
≥60dB
Intermodulation
≥65dB
Spurious Rejection
Audio response
+1~-3dB (0.3-3KHz)
+1~-3dB (0.3~2.55KHz)
Signal to noise ratio
≥45dB
≥40dB
Audio Distortion
Audio output power
≤5% ≥2W±10%
TRANSMIT
Output power
25W / 20W (VHF / UHF)
Modulation Mode
16KΦF3E
11KΦF3E
Channel Power
≥60B
signal to noise ratio
≥36dB
Parasitic harmonic
+1--3dB (0.3-3KHz)
+1--3dB (0.3-2.55KHz)
Audio distortion
≤5%
