TECHNICAL SPECIFICATIONS
GENERAL
Specification
Value
Frequency Range (MHz)
VHF: 136~174MHZ (220~260MHz) UHF: 400~480MH2 (350~390MHz)
Memory channels
200
Frequency stability
±2.5ppm
Frequency step (kHz)
2.5K/5.0K/6.25K/10.0K/12.5K/25.0K
Squelch Setup
CARRIER / CTCSS /DCS / 5Tone /2TONE / DTMF
Antenna impedance
50 0hm
Operating temperature
-20°C to +60°℃
Supply voltage
13.8V DC±15%:
Dimension
98(W) × 43(H) × 126(D) mm / 103(W) × 47(H) × 126(D) mm
Weight
448g
Operating Temperature
-5°F - +140°F
RECEIVER
Broadband
Narrow band
Sensitivity
≤0.25μV
≤0.35μV
Channel choice
≥70dB
≥60dB
Intermodulation
≥65dB
Spurious Rejection
Audio response
+1~3dB (0.3-3KHz)
+1~-3dB (0.3~2.55KHz)
Signal to noise ratio
≥45dB
≥40dB
Audio Distortion
≤5%
Audio output power
≥2W±10%
TRANSMIT
Output power
25W / 20W (VHF /UHF)
Modulation Mode
16KΦF3E
11KΦF3E
Channel Power
≥60B
≥36dB
Parasitic harmonic
+1--3dB (0.3-3KHz)
+1--3dB (0.3-2.55KHz)
Audio distortion
2026-04-03 1
SGS -1.pdf
SGS -2.pdf
KT-8900_Radio Report_PMR.pdf
KT-8900_Safety Report.pdf
QYT Electronics Co., Ltd. Announces New Certification from JARD
QYT Electronics Co., Ltd. Invites You to Visit Us at the Global Sources Consumer Electronics Show in Hong Kong
QYT QYT28 Handheld Transceiver Featured in Japan's HAM world Magazine September 2024 Issue
