QYT HF-18 27MHz CB Radio AM FM SSB Color Display Transceiver

The QYT HF-18 is a new 27MHz CB radio supporting AM, FM and SSB modes. It adopts a humanized color display interface and comes with receive & transmit working modes. It supports both whole unit and single battery charging. This model shares the same functions as HF-78, without battery configuration for more competitive price. Ideal for CB radio enthusiasts and short range communication. Feel free to contact us to get detailed customization plans and quotations.

Availability:



Inquire

Model:
HF-18
Brand:
QYT

QYT HF-18 27MHz CB Radio AM FM SSB CB Transceiver 27Mhz CB Radio with Color Display HF-18 CB Ham Radio 27MHz Citizen Band Radio

Product Description

We offer comprehensive customized services for the QYT HF-18 CB radio. Customizable options include printed brand LOGO, outer packaging boxes, antenna parameters, power cable design and other hardware specifications. We can also adjust partial internal circuit structures and optimize AM, FM & SSB function parameters according to your demands.

HF-18 27MHz CB Transceiver AM FM SSB Color Screen

Main Functions
No.	Function
1	Support Both Whole Machine and Single Battery Charging
2	Humanized Color Display Interface
3	Multiple Working Modes: Receive Mode, Transmit Mode
4	TUNE Mode, VFO Mode, SPLIT Mode
5	DSP Digital Signal Processing Noise Reduction
6	Automatic Notch Filter
7	Spectrum Dynamic Waterfall Display
8	Multifunctional Instrument: SWR Standing Wave Ratio Meter
9	AVD Audio Frequency Meter, ALC Signal Modulation Meter

General Specification
Item	Specification
Frequency Range RX	1.8-30MHz TX-1.8-30MHz
Operating Mode	SB（J3E), CW, AM, FM, FREE-DV
Battery Capacity	3800mAh Lithium-polymer Batery（DC11.1V）
Operating Voltage	DC13-15V
Output Power	Maximum15w
Receiving Sensitivity	<-95dBm
Operating Temperature	20℃-+60℃
Antenna Impedance	50Ω
Frequency Stability	±1.5ppm
Dimensions (WHD)	208×81.09×73.2mm
