QYT HF-78 15W 27MHz CB Radio Type-C Charging CW AM FM SSB Transceiver

The QYT HF-78 is a portable long-range 27MHz CB radio supporting CW, AM, FM and SSB modes. It is equipped with a built-in 3800mAh lithium battery for outdoor operation. It supports Type-C USB charging, both whole machine charging and independent single battery charging. It adopts DSP noise reduction, automatic notch filter and waterfall spectrum display. Great for outdoor portable CB communication and ham radio users. Feel free to contact us to get detailed customization plans and quotations.

Availability:



Inquire

Model:
HF-78
Brand:
QYT

QYT HF-78 27MHz CB Radio 15W Portable SSB AM FM CB Transceiver 27Mhz CB Radio with 3800mAh Battery Type-C Charging HF CB Ham Radio Long Range Portable CB Radio

Product Description

We offer comprehensive customized services for the QYT HF-78 CB radio. Customizable options include printed brand LOGO, outer packaging boxes, antenna parameters, power connector design and other hardware specifications. We can also adjust partial internal circuit structures and optimize CW, AM, FM & SSB function parameters according to your demands.

HF-78 Portable 27MHz CB Radio 15W SSB AM FM with Battery

Main Functions
No.	Function
1	Portable, 3800mAh Large Capacity Lithium Battery, Convenient for Outdoor Use
2	Support Type-C USB Port Charging
3	Support Both Whole Machine and Single Battery Charging
4	Humanized Color Display Interface
5	Multiple Working Modes: Receive Mode, Transmit Mode, TUNE Mode, VFO Mode, SPLIT Mode
6	DSP Digital Signal Processing Noise Reduction
7	Automatic Notch Filter
8	Spectrum Dynamic Waterfall Display
9	Multifunctional Instrument: SWR Standing Wave Ratio Meter, AVD Audio Frequency Meter, ALC Signal Modulation Meter

General Specification
Item	Specification
Frequency Range RX	RX: 1.8–30MHz; TX: 1.8–30MHz
Operating Mode	SSB(J3E), CW, AM, FM, FREE-DV
Battery Capacity	3800mAh Lithium-polymer Battery (DC 11.1V)
Operating Voltage	DC13-15V
Output Power	Maximum15w
Receiving Sensitivity	<-95dBm
Operating Temperature	20℃-+60℃
Antenna Impedance	50Ω
Frequency Stability	±1.5ppm
Dimensions (WHD)	208×81.09×73.2mm
Weight (Battery and Mounting Bracket Included)	918.8g

No.	Accessory
1	Hand Microphone
2	Battery
3	AC Adaptor
4	Single Plug Power Cord
5	Power Conversion Plug
6	Side Handles
