QYT HF-98 Full Frequency Transceiver WIFI CW FT8 SSB SDR 3D Waterfall Spectrum

The QYT HF-98 is a full-frequency amateur radio transceiver equipped with a 7-inch touch screen and 3D waterfall spectrum display. It supports CW, FT8 and SSB modes, built-in WiFi for remote operation and firmware upgrade. It also comes with auto/manual notch filters and digital noise reduction to improve receiving quality. Perfect for ham radio operators and professional radio users. Feel free to contact us to get detailed customization plans and quotations.

Availability:



Inquire

Model:
HF-98
Brand:
QYT

WIFI SSB CW FT8 Radio HF-98 Full Frequency SDR Transceiver 3D Waterfall Spectrum HF Radio Transceiver Full Band SDR Transceiver with Touch Screen HF-98 Amateur Radio Transceiver

Product Description

We offer comprehensive customized services for the QYT HF-98 full frequency transceiver. Customizable options include printed brand LOGO, outer packaging boxes, antenna interface parameters, power supply design and other hardware specifications. We can also adjust partial internal circuit structures and optimize SDR & FT8 function parameters according to your demands.

HF-98 Full Band SDR Transceiver 3D Waterfall Spectrum WIFI

The QYT HF-98 is a high-performance HF radio, integrating advanced technology and rich features, designed for amateur radio enthusiasts and professional users.

Core Features
No.	Feature
1	All Mode Full Band HF Transceiver
2	Big 7" capacitive multi-touch screen, clear display under sunlight
3	Built-in CW decode, FT8 encode and decode (no additional device required)
4	Most powerful FPGA support, 3D spectrum, waterfall display
5	Built-in WiFi, online radio displayed after networking
6	Band-pass Filter
7	DDC/DUC technology, 0-750MHz all mode receiving
8	20W/200W high power output

Main Functions
No.	Function
1	Built-in 16G TF card, supports multiple recordings and playback, recording call, CW mode with 5 recordings
2	Online OTA upgrade or TF card flash upgrade
3	Multi scene mode selection, fully open source software and hardware can be modified as per needed
4	Built-in USB sound card for easy connection
5	All aluminum anodizing housing, precision design and production
6	Built-in antenna tuner
7	Low Noise Amplifier (LNA)

General Specification
Item	Specification
RX Frequency	0 MHz - 750 MHz
TX Frequency	0 MHz - 200 MHz (Amateur Band); 360 MHz - 480 MHz (Frequency Doubling Mode)
Antenna Type	Dual Antenna Input
Modulation Type (TX/RX)	CW, LSB, USB, AM, FM, WFM, DIGI
Variable Attenuator	0-31dB
ADC Dynamic Range	~100dB
Supply Voltage	13.8V (Overvoltage and Polarity Reverse Protection)
RX Current	~0.7A (3'2 QRP), 0.9A (7'BIG)
TX Current	~2.5A+(QRP), 15A+(BIG)
Dimensions (W × H × D)	340 × 140 × 135mm
Weight	2903g
Output Power (QRP++ DB5AT)	20W(HF), 7W(VHF)(RS-988)
Output Power (RU4PN/WF-100D)	100W(HF), 50W+(VHF)(RS-998)
