QYT KT-780Plus VHF Single Band Mobile Ham Radio 100W High Power Vehicle & Boat Transceiver

The QYT KT-780Plus is a high-power VHF single band mobile ham radio for cars and boats. It supports optional 12V power supply and delivers up to 100W output power for long-distance communication. Featuring steady signal performance and strong signal penetration, it performs excellently in complex environments. This analog mobile radio is built for stable continuous operation. It fits multiple application scenarios, such as marine communication, vehicle fleets, construction sites and outdoor projects. Reliable hardware ensures clear audio even under poor signal conditions. Contact us to get full specifications and quotations.

Availability:



Inquire

Model:
KT-780Plus
Brand:
QYT

Walkie Talkie Mobile Radio 100W VHF Single Band Mobile Radio High Power Vehicle & Boat Ham Radio Long Range Marine Mobile Transceiver

Product Description

Specification:
Frequency Range	136-174MHz
Number of channels	VHF: 256 Channels
Channel spacing	25KHz/ 20KHz/12.5Khz
Phase lock step step	2.5KHz/5KHz/6.25 KHz/10 KHz/12.5 KHz/25 KHz
Working voltage	13.8V DC±15%
Squelch way	CARRIER/CTCSS/DCS/5Tone/2Tone/DTMF
Frequency stability	±2.5ppm
Operat temperature	-20+60℃
Dimension	140(W)43(H)172(D)mm
Weight	1.03kg
Receive(ETSI EN 300 086 Standarddized.Test)
	Broadband	Narrow Band
Sensitivity	≤0.25μν	≤0.35μν
Channel Cholce	≥70db	≥60db
Intermodulation	≥65db	≥60db
Spurious Rejection	≥70db	≥70db
Audio Response	+1~~3db(0.3~3KHz)	+1~~3db(0.3~2.55KHz)
Signal to noise radio	≥45db	≥40db
Audio Distortion	≤5%
Audio output power	≥2W@10%
Transmit(ETSI EN 300 086 Standarddized.Test)
	Wideband	Narrow Band
Output Power	VHF 75W(15A)/UHF 55W(10A)
Modulation Mode	16KΦF3E	11KΦF3E
Channel Power	≥70db	≥60db
Signal to noise radio	≥45db	≥40db
Parasitic Harmonic	≥60db	≥60db
Audio Response	+1~~3db(0.3~3KHz)	+1~~3db(0.3~2.55KHz)
Audio Distortion	≤5%
